No Antenna Low Power Consumption IoT Modul Small Size Cansec LR1268Na-G SX1268 Wireless Module Transmission LoRa

No Antenna Low Power Consumption IoT Modul Small Size Cansec LR1268Na-G SX1268 Wireless Module Transmission LoRa

Parameter		Min	Typ	Max	Unit
Operating Voltage		2.7	-	3.6	V
Operating Temperature		-20	-	+70	℃
Current Consumption	Sleep Mode	-	0.1	-	uA
	Receive mode	-	11.7	-	mA
	Transmit Mode (RFOP =+20dBm, on PA_BOOST)	-	117	-	mA
TX Power (For Carrier)		-	18	20	dBm
RX Sensitivity (For Lora Modulation)		-	-	-139	dBm

No Antenna Low Power Consumption IoT Modul Small Size Cansec LR1268Na-G SX1268 Wireless Module Transmission LoRa

1. The LR1268NA-G module is designed based on SX1268. The SX1278 incorporates the LoRaTM spread spectrum modem which is capable of achieving significantly longer range than existing systems based on FSK or OOK modulation.

2. LoRaTM also provides significant advances in selectivity and blocking performance, further improving communication reliability.

3. For maximum flexibility the user may decide on the spread spectrum modulation bandwidth (BW), spreading factor (SF) and error correction rate (CR). Another benefit of the spread modulation is that each spreading factor is orthogonal - thus multiple transmitted signals can occupy the same channel without interfering. This also permits simple coexistence with existing FSK based systems. Standard GFSK, FSK, OOK, and GMSK modulation is also provided to allow compatibility with existing systems or standards such as wireless MBUS and IEEE 802.15.4g.

Applications
Automated Meter Reading.
Home and Building Automation.
Wireless Alarm and Security Systems.
Industrial Monitoring and Control
Long range Irrigation System

​

FAQ

Q1: Are you a factory or trade company?

A1: We are a professional factory with 28 years experience.

Q2: Can you accept OEM/ODM?

A2: Sure, we have rich OEM&ODM experience.

Q3: Do you have quality assurance?

A3; Each of our products has undergone quality testing and has two years of free after-sales service.

We are Beijing JiaAn Electronics Technology, founded in 1994; Taiwan invested.

We are the third-party partner of Texas Instruments and the supplier of Arrow Electronics;

along with over 25 years of experience in the RF industry,

we developed a team with deep technical background,

high performance and quick response timing to co-operate with our clients globally.

About 70 per cent of our clients are overseas, and 80 per cent of our clients are returning customers.

All our products require layers and layers of inspections, testing and quality control procedures before shipping;

Offering our client a trustworthy and long-lasting partnership.
