    2uA ST-STM32WLE Lora RF Module Low Power Consumption

    Ask Lasest Price
    Brand Name : Cansec Wireless
    Model Number : LRW32NA-C
    Price : USD5.5$ Per Piece
    Payment Terms : T/T
    Supply Ability : 20000000 units per year
    Delivery Time : 5-8 weeks
    • Product Details
    • Company Profile

    2uA ST-STM32WLE Lora RF Module Low Power Consumption

    2uA ST-STM32WLE Lora RF Module Low Power Consumption

    Parameter
    Min
    Typ
    Max
    Unit
    Operating Voltage
    2.5
    3.3
    3.7
    V
    Operating Temperature
    -20
    -
    70
    °C
    Current
    Consumption
    Rest
    -
    2
    uA
    Receive
    -
    12.5
    mA
    Transmit Mode
    -
    120
    mA
    TX Power
    -
    20
    dBm
    RX Sensitivity
    -
    -140
    dBm
    1. The LRW32 long-range wireless and ultra-low-power devices embed a powerful and ultra-low-power radio compliant LPWAN radio solution: LoRa® (only available in STM32WLE5xx), (G)FSK, (G)MSK, and BPSK.
    2. The devices embed high-speed memories (Flash memory up to 256 Kbytes, SRAM up to 64 Kbytes), and an extensive range of enhanced I/Os and peripherals.
    3. These devices offer a 12-bit ADC, a 12-bit DAC low-power sample-and-hold, two ultra-low-power comparators associated with a high-accuracy reference voltage generator.
    4. The devices embed a low-power RTC with a 32-bit sub-second wakeup counter, one 16-bit single-channel timer, two 16-bit four-channel timers (supporting motor control), one 32-bit four-channel timer and three 16-bit ultra-low-power timers.
    Application
    Smart meters
    Supply chain and logistics
    Building automation
    Agricultural sensors
    Smart cities
    Retail store sensors
    Asset tracking
    Street lights
    Parking sensors
    Environmental sensors
    Healthcare
    Safety and security sensors
    Remote control applications

    FAQ
    Q1: Are you a factory or trade company?
    A1: We are a professional factory with 25 years experience.
    Q2: Can you accept OEM/ODM?
    A2: Sure, we have rich OEM&ODM experience.
    Q3: Do you have quality assurance?
    A3; Each of our products has undergone quality testing and has two years of free after-sales service.
