| Brand Name : | Cansec Wireless |
| Model Number : | BLE52810SA-A |
| Price : | USD 3.11$ per piece |
| Payment Terms : | T/T |
| Supply Ability : | 2000000 pieces per year |
| Delivery Time : | 3~6 weeks |
On-Chip Nfc Tag For Out-Of-Band (Oob) Pairing Cansec Ble52810SA-A Nordic NRF52810-QFAA Blue Tooth Plugin Module For IoT
On-Chip Nfc Tag For Out-Of-Band (OOB) Pairing Cansec Ble52810SA-A Nordic NRF52810-QFAA Blue Tooth Plugin Module For IoT
The BLE52810 module is based on nRF52810 SoC which is a powerful, highly flexible ultra-low power multiprotocol SoC ideally suited for Bluetooth® Low Energy, ANT and 2.4GHz ultra-low-power wireless applications.
Key Feature
- Single-chip, highly flexible, 2.4GHz multi-protocol SoC
- 32-bit ARM Cortex-M4 Processor
- 1.7v to 3.6v operation
- Support concurrent Bluetooth low energy / ANTprotocol operation
- On-Chip NFC tag for Out-of-Band (OOB) Pairing
- Up to +3dBm output power
- -96dBm sensitivity, Bluetooth low energy
- Thread-safe and run-time protected
- Event-driven API
- 2 data rates (2Mbps/1Mbps)
- PPI - maximum flexibility
- Power-efficient applications and code simplification
- Automated power management system with automatic power management of each peripheral
- Configurable I/O mapping for analog and digital I/O
- 3 x Master/ Slave SPI
- 2 x Two-wire interface (i2c)
- UART (RTS/CTS)
- 3 x PWM
- AES HW encryption
- 12-bit ADC
- Real-Time Counter (RTC)
- Digital microphone interface (PDM)
|
|
